AIS Hose & Braid (American Iron & Steel Compliant)

Penflex offers a line of flexible metal hose and braid compliant with American Iron & Steel (AIS) requirements for projects that require 100% domestically sourced raw materials.

Manufactured at our Gilbertsville, PA facility using stainless steel strip and wire melted and produced in the United States, AIS hose and braid provide the same proven geometry and performance characteristics as our standard P4 and 700 Series products.

AIS compliance is required for iron and steel products used in projects receiving assistance through the Clean Water and Drinking Water State Revolving Fund programs. While these requirements apply specifically to water infrastructure projects, products manufactured to AIS standards may also support broader domestic sourcing initiatives, including Build America, Buy America (BABA) and Defense Federal Acquisition Regulation Supplement (DFARS).

Defined part numbers and approved supplier lists support full traceability from raw material through finished product, simplifying procurement.

Benefits

Flexible, yet durable, midweight construction
Good corrosion resistance
High pressure ratings
Non-porous, leak-tight performance
Made in accordance with ISO 10380 (through 4″)
Available in compressed pitch

Technical Specifications

Construction: Annular hose with a standard pitch
Hose material: 316L stainless steel
Braid material: 304L
Other alloys available upon request
Sizes: 3/4″ through 12″
Offered as: Hose and braid (boxed separately) or single-braided hose on reels

AIS Bare Hose in Boxes


Nom I.D. (in.)	Ft/Box	Part Number	Nom O.D. (in.)	Maximum Working Pressure @70ºF (PSIG)	Dynamic Bend Radius (in.)	Static Bend Radius (in.)	Weight per Foot (Lb.)
3/4”	100	4016-012-AIS	1.21	70	8	2.25	0.39
1”	100	4016-016-AIS	1.51	40	9	2.75	0.53
1-1/2”	100	4016-024-AIS	2.19	20	12	4	0.84
2”	50	4016-032-AIS	2.61	15	15	5	0.90
3”	20-25	4016-048-AIS	3.78	10	22	9	1.21
4”	20-25	4016-064-AIS	4.85	8	27	13	1.69
6”	20-25	716-096-AIS	6.87	5	36	19	3.47
8”	20-25	716-128-AIS	9.12	6	40	20	5.56
10”	10-20	716-160-AIS	11.18	5	50	25	6.80
12”	10-20	716-192-AIS	13.17	3	60	30	9.02

AIS Loose Braid in Boxes


Nom I.D. (in.)	Ft/Box	Part Number	Braid Construction	Weight per Foot (Lb.)
3/4”	110	P4-B4004-012-AIS	36 x 9 x .014	0.23
1”	110	P4-B4004-016-AIS	36 x 10 x .014	0.26
1-1/2”	110	P4-B4004-024-AIS	48 x 10 x .016	0.45
2”	110	P4-B4004-032-AIS	48 x 10 x .020	0.71
3”	110	P4-B4004-048-AIS	72 x 9 x .020	0.79
4”	110	P4-B4004-064-AIS	72 x 11 x .020	0.99
6”	100-110	1SB-096-DOM*	96 x 12 x .020	1.28
8”	100-110	1SB-128-DOM*	96 x (21 x .024)	3.88
10”	110	1SB-160-DOM*	96 x (25 x .028)	6.10
12”	110	1SB-160-DOM*	96 x (25 x .028)	5.81

*These part numbers, while made with US-sourced materials, are not AIS-compliant due to manufacturing location.

AIS Single Braided Hose on Reels


Nom I.D. (in.)	Ft/Reel	Part Number	Braid Construction	Braid Coverage (%)	Nom O.D. (in.)	Maximum Working Pressure @ 70ºF (PSIG)	Nominal Burst	Dynamic Bend Radius (in.)	Static Bend Radius (in.)	Weight per Foot (Lb.)
3/4”	500	P4-H4016-B4004-012-AIS	36 x 9 x .014	95	1.28	940	3,760	8	2.25	0.62
1”	450	P4-H4016-B4004-016-AIS	36 x 10 x .014	92	1.58	630	2,520	9	2.75	0.79
1-1/2”	350	P4-H4016-B4004-024-AIS	48 x 10 x .016	93	2.28	500	2,000	12	4	1.29
2”	250	P4-H4016-B4004-032-AIS	48 x 10 x .020	95	2.73	532	2,128	15	5	1.61
3”	200	P4-H4016-B4004-048-AIS	72 x 9 x .020	93	3.88	400	1,600	22	9	2.00
4”	150	P4-H4016-B4004-064-AIS	72 x 11 x .020	91	4.98	300	1,200	27	13	2.68

Download AIS Series Spec Sheet

Download Full Metal Hose Catalog
